Main Purpose
This equipment is mainly used for transparent film three dimension wrapping of single piece or multi piece square object in such industries as medicine, cosmetics, health products, food, etc.
Performance Features
1. This 3D packing machine is elaborately designed and modified on the basis of absorbing and digesting advanced machine from aboard.
2. It adopts PLC control, its controlled by servo motor. the film length can be set freely
3. Sealing part is firm, neat and beautiful. Th product is anti-counterfeiting, moist-proof and dust-proof effects.
4. The 3D packing machine is stable running, compact structure, simple operation and convenient maintenance.
5. it can replace heat shrink packaging machine.
Main Technical Parameters
Main Machine L2200*W960*H1760mm
Conveyor Table L1500*W200*H880mm
Machine Details
Model
WS-350B
Speed
15-40Bags/minute
Carton Size
L50-300*W40-220*H10-90mm
Voltage
220V/50HZ 380V/50HZ
Total Power
3.75KW
Equipment Size
Compressed Air Pressure
0.6Mpa
Weight
750kg
